    E312/200B/320/330/325/330 Excavator Sprocket For Undercarriage Elements Part No 964327 6Y5685

    Ask Lasest Price
    Brand Name : YT
    Model Number : E312/200B/320/330/325/330
    Certification : ISO、CE
    Price : $4.90 - $20.00/pieces
    Payment Terms : T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow
    Supply Ability : 10000 PCS/Month
    Delivery Time : FOB Xiamen or any Chinese port:25-30days . If there are any parts in stock ,our delivery time is only 7-10 days.
    • Product Details
    • Company Profile

    E312/200B/320/330/325/330 Excavator Sprocket For Undercarriage Elements Part No 964327 6Y5685

    Detail Information

    Material:ZG40Mn Or 20CrMnTi SteelTechnique:Precision Casting
    Quality:Hardness HRC 42-52Brand Name:YT
    Depth:15mmWarranty Time:1 Year
    Deliver Time:Within 7-30 DaysPackage:Standard Export Packaging

    Product Description

    E312/200B/320/330/325/330 Excavator Sprocket Undercarriage Parts

    for Construction Machinery

    1. What Is sprocket ?

    The excavator sprocket of an excavator constitutes a vital part of its propulsion system, serving an indispensable function. Its fundamental roles span four pivotal areas: the efficient conveyance of mechanical power, the provision of sturdy structural support and traction to guarantee smooth operation, the augmentation of operational stability and resistance to seismic forces, and ultimately, the direct influence it wields on work efficiency and production output.

    E312/200B/320/330/325/330 Excavator Sprocket For Undercarriage Elements Part No 964327 6Y5685

    2. Advantages / Features


    The materials for the driving wheel can be selected based on the machine size and mining application, including options such as G33MnCrMo5, G33Mn4, SCMnCr4B, ZG40Mn, and ZG35Mn. After being normalized, the base hardness of the driving wheel blank reaches above HB235. The driving teeth, after being induction hardened around the entire circumference and tempered at low temperature, achieve a surface hardness of HRC48-54, with a hardening depth of 5-10mm (HRC45) or more. This ensures precise power transmission even in harsh working conditions and provides excellent wear resistance, significantly extending the product's service life and reducing customer operating costs.


    Casting D7G Segment Sprocket 8E4675 For Excavator 0


    3. Design/Structure

    E312/200B/320/330/325/330 Excavator Sprocket For Undercarriage Elements Part No 964327 6Y5685

    MAIN PARAMETERS

    ModelABCDGeneral Model
    E180232241516*50MS180,E240
    E200B211441520*50thick
    E240232241616*50E180,MS180
    E300231645020*60MS280
    E300251645120*60
    E300B231645020*60LS310
    E312/HD450/YC135211532416*45thickE110B,E311B,E311,E310,E314C,SKO45,HD400/450/500/510/512
    YC135,YC125-8,DH150,SH120-5,Max O.D585,链通开口宽68
    E320B211645620*50thickE322,E324,E320A/B/C/D通用,E318
    E320C252456120*50thickE450
    E352211845022E329
    E330231651020*60thickE330B,E336,E337
    E345232057524*60

    4. why choose us?



    (1). Large-scale factory & 1,400m² warehouse, thousands of products, quality & inventory guaranteed.

    (4). One-stop service: purchasing, loading, low-cost procurement, worry-free.

    (5). Prompt responses, rapid shipments, strong inventory support ensures fast delivery.

    (6). Comprehensive after-sales service, one-on-one assistance. Warranty: oil leakage, wheel fracture, provide logo photo, replace with new wheel.


    5. Manufacturing Processes

    OEM Bulldozer Undercarriage Segment Replacement Drive Sprocket Ring 2



    6. Hot Sale Products


    7.Customer Feedback

    E312/200B/320/330/325/330 Excavator Sprocket For Undercarriage Elements Part No 964327 6Y5685
